Single Lab Faucet Control
Lab Faucet Specifications
General Overview
- Model: Single Temperature Control Lab Faucet
- Mounting: Deck Mounted
- Features: Rigid Vacuum Breaker Nozzle, Serrated Tip
Detailed Description
This single-temperature control lab faucet is deck-mounted with a single hole. It features a polished chrome-plated brass body with a 7″ riser. The faucet is outfitted with a polished chrome-plated swivel nozzle that includes a vacuum breaker and a serrated tip outlet. It is designed with a 0.5 GPM flow control, a compression cartridge with a spring check, and a 4-arm lab handle. The faucet connects via a 1/2″ NPSM male inlet.
This faucet is certified to ASME A112.18.1 / CSA B125.1, NSF 61-Section 9, NSF 372, and ASSE 1001. It also fulfills ADA ANSI/ICC A117.1 requirements.
Performance Specifications
- Pressure Range: 20 – 125 psi (1.38 bar – 8.62 bar)
- Temperature Range: 40ºF – 140ºF (4.44ºC – 60ºC)
Features & Benefits
- Single-hole deck mount mixing faucet with polished chrome-plated brass body
- Polished chrome-plated swivel vacuum breaker nozzle, includes a lock washer to convert swing nozzle to rigid
- Serrated tip outlet with 0.5 GPM flow control and washer
- Quarter-turn Eterna compression cartridge with spring check
- 4-arm handle with color-coded index
- 1/2″ NPSM male inlet
- Material: Polished chrome plated brass body, tubular spout and handle
Variations
- Includes vandal-resistant anti-rotation screws in the base, a vandal-resistant handle, and vandal-resistant “LocTited” joints
- Nozzle swivels at vacuum breaker
